ListerBell STR Lancia Stratos Replica - 2022

This car has now been sold, thank you for your comments and interest.

IVA’d in November 2021, Correctly registered as an LB STR from March 2022. Currently on a 22 plate but can be changed to any personal plate which pre dates March 22.

Covered 800 miles from new.

The car has been customer built over a number of years using a ListerBell STR road chassis with full integral roll cage. The car has been built as a RHD but could be converted to LHD by an overseas buyer.

Please note this is a private sale and is only advertised on behalf of the customer. All enquiries should be made directly to the owner who can be contacted via email on- PeterSunray39@gmail.com The car is located on the South coast of the UK in the Arundel/Littlehampton area.

Description

Engine and Gearbox:

Alfa Romeo 3.0 V6 CF2 Busso engine, supplied & rebuilt by AutoLusso Bournemouth, the engine is fitted with the solid flywheel from a 2.5 litre V6 156 and this has been balanced to the engine by Vibration Free of Bicester. The engine is also fitted with the plenum chamber from a Lancia Thesis which has the “Lancia” name cast in to it.

The engine is fitted with the standard Alfa tubular exhaust manifolds & these are mated to the LB Stradale exhaust system which features twin 5” stainless silencers with integral catalysts.
Engine management is provided by a stock Alfa CF2 ECU, which also maintains the original Alfa ignition immobiliser for added security.

Cooling is provided by an alloy cored radiator with twin 11” ECU controlled radiator fans
Power is around the 220Bhp mark as per the original Alfa donor.
A 6 speed manual gearbox is fitted which has been rebuilt by Auto Europe of Gatwick using new GTA internals and also a Quaife ATB differential

Running Gear:

Suspension is provided by the standard STR arrangement of custom fabricated wishbones with a double wishbone arrangement at the front and a strut type rear set up which are connected to aircraft grade billet alloy uprights.
Damping is provided by by Gaz Gold coil overs at the front & equivalent struts at the rear.
Front & rear anti roll bars are fitted.

Braking is provided by a dual circuit braking system which utilises a bias adjustable Wilwood pedal box with twin master cylinders at the pedal end. At the other end of the stainless braided ptfe lines there are 4 pot brake calipers which are clamping on 300mm ventilated discs via EBC pads both front and rear. There are also dedicated Brembo handbrake calipers acting on each rear wheel.

Interior:

LB seat shells upholstered in grey leather with matching alcantara complete with a Stratos logo embroidered into the seat backs. The seats are mounted on Sabelt seat sliders for adjustability. Blue Sabelt FIA compliant 4 point harnesses fitted

Stradale type dash surround and binnacle trimmed in grey leather along with matching leather central tunnel sections. Black powder coated dash fascia fitted with LB supplied electronic gauges with Stratos inspired artwork
Grey carpet set as supplied by LB along with with powder coated sill covers and foot rest.
Heated front screen

Reversing camera
3 speed demist & heater fan with switchable air conditioning

Exterior:

Stradale type bodywork finished in RAL 5015 sky blue gelcoat with contrasting black rear louvre , light surrounds & spoilers.

The car is fitted with two piece coffin spoke wheels in 8 x 16” F & 9 x 16” R sizes which are fitted with Toyo Proxes tyres in 225/45/16 F & 245/45/16” R sizes

Other:

The car comes with a “shower cap” for when parked outside over night and a hand held fire extinguisher.
